2015 BamX BX70-DB Trailstar Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2015 BamX BX70-DB Trailstar.

Basic Specs

Year2015
MakeBamX
ModelBamX BX70-DB Trailstar
CostUS$ 999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement72.00 ccm (4.39 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression8.8:1
Bore/Stroke47.0 x 41.4 mm (1.9 x 1.6 inches)
Valves/Cylinder
FuelingCarburettor
IgnitionCDI
Exhaust
LubricationPressure/Splash
CoolingAir

Drivetrain

GearboxAutomatic
Final DriveChain
Clutch
Driveline

Performance

Horespower3.60 HP (2.6 kW)
Torque4.20 Nm (0.4 kgf-m or 3.1 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity4.00 litres (1.06 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionDual Shocks
Front Travel
Rear SuspensionSwing Arm Mono Shock
Rear Travel
Seat
Seat Height711 mm (28.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance254 mm (10.0 inches)
Wheelbase991 mm (39.0 inches)
Dry Weight49.9 kg (110.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre2.50-14
Rear Tire/Tyre2.75-12
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the BamX BX70-DB Trailstar. This Minibike, cross model is powered by a Single cylinder, two-stroke engine with 72.00 ccm (4.39 cubic inches) of actual displacement before 8.8:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 3.60 HP (2.6 kW) horsepower and 4.20 Nm (0.4 kgf-m or 3.1 ft.lbs) torque. According to our records engine heat of the BamX BX70-DB Trailstar is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 2.50-14 and the rear is 2.75-12 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The BamX BX70-DB Trailstar was launched in 2015, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
