2015 Ducati Monster 796 Corse Stripe Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2015 Ducati Monster 796 Corse Stripe.

Basic Specs

Year2015
MakeDucati
ModelDucati Monster 796 Corse Stripe
Cost

Engine

Displacement803.00 ccm (49.00 cubic inches)
TypeL-Twin
DetailsV2, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke88.0 x 66.0 mm (3.5 x 2.6 inches)
Valves/Cylinder2
FuelingInjection. 45mm throttle body 45 mm with stepper motor
Ignition
ExhaustLightweight 2-1-2 system with catalytic converter with twin lambda probes
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchAPTC wet multiplate with hydraulic control
DrivelineChain; Front sprocket 15; Rear sprocket 45. Primary drive: Straight cut gears; Ratio 1.85.

Performance

Horespower87.00 HP (63.5 kW)
Torque78.00 Nm (8.0 kgf-m or 57.5 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 gallons)
Emissions

Chassis

Frame TypeTubular chrome moly steel trellis, casted aluminium subframe
Rake24.0°
Trail87 mm (3.4 inches)
Front Suspension43mm upside-down forks
Front Travel120 mm (4.7 inches)
Rear SuspensionProgressive linkage with preload and rebound Sachs adjustable monoshock
Rear Travel148 mm (5.8 inches)
SeatDual seat
Seat Height770 mm (30.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,179 mm (46.4 inches)
Total Length2,114 mm (83.2 inches)
Total Width784 mm (30.9 inches)
Ground Clearance
Wheelbase1,450 mm (57.1 inches)
Dry Weight169.0 kg (372.6 pounds)
Wet Weight188.0 kg (414.5 pounds)

Wheels & Brakes

Front Tire/Tyre120/60-17
Rear Tire/Tyre160/60-17
Front BrakesDouble disc. ABS. Four-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Two-piston calipers.
Rear Brake Diameter245 mm (9.6 inches)
Wheels5-spoke in light alloy

Comments

It appears you're interested in specifications for the Ducati Monster 796 Corse Stripe. This Naked bike model is powered by a L-Twin V2, four-stroke engine with 803.00 ccm (49.00 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. 45mm throttle body 45 mm with stepper motor allowing this machine to produce its 87.00 HP (63.5 kW) horsepower and 78.00 Nm (8.0 kgf-m or 57.5 ft.lbs) torque. According to our records engine heat of the Ducati Monster 796 Corse Stripe is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/60-17 and the rear is 160/60-17 . The entire package is supported by the frame, Tubular chrome moly steel trellis, casted aluminium subframe . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Four-piston calipers. front brakes and Single disc. Two-piston calipers. rear brakes. The Ducati Monster 796 Corse Stripe was launched in 2015, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
