2015 Honda CBR 300R ABS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2015 Honda CBR 300R ABS.

Basic Specs

Year2015
MakeHonda
ModelHonda CBR 300R ABS
TypeSport
CostUS$ 4899. Prices depend on country, taxes, accessories, etc.

Engine

Displacement286.00 ccm (17.45 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke76.0 x 63.0 mm (3.0 x 2.5 inches)
Valves/Cylinder4
FuelingInjection. PGM-Fi, 38mm throttle body
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet multiplate
Driveline

Performance

Horespower30.44 HP (22.2 kW)
Torque27.00 Nm (2.8 kgf-m or 19.9 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption3.31 litres/100 km (30.2 km/l or 71.06 mpg)
Fuel Capacity13.00 litres (3.43 gallons)
Emissions76.8 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeDiamond Steel. Swing arm: 573.6mm.
Rake25.3°
Trail98 mm (3.9 inches)
Front Suspension37mm conventional fork
Front Travel103 mm (4.1 inches)
Rear SuspensionPro-Link single shock with five positions of spring preload adjustability
Rear Travel118 mm (4.7 inches)
Seat
Seat Height785 mm (30.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,127 mm (44.4 inches)
Total Length2,030 mm (79.9 inches)
Total Width710 mm (27.9 inches)
Ground Clearance145 mm (5.7 inches)
Wheelbase1,380 mm (54.3 inches)
Dry Weight
Wet Weight164.0 kg (361.6 pounds)

Wheels & Brakes

Front Tire/Tyre110/70-17
Rear Tire/Tyre140/70-17
Front BrakesSingle disc. Hydraulic.
Front Brake Diameter296 mm (11.7 inches)
Rear BrakesSingle disc. Hydraulic.
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda CBR 300R ABS. This Sport model is powered by a Single cylinder, four-stroke engine with 286.00 ccm (17.45 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-Fi, 38mm throttle body allowing this machine to produce its 30.44 HP (22.2 kW) horsepower and 27.00 Nm (2.8 kgf-m or 19.9 ft.lbs) torque. According to our records engine heat of the Honda CBR 300R ABS is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 110/70-17 and the rear is 140/70-17 . The entire package is supported by the frame, Diamond Steel. Swing arm: 573.6mm.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. front brakes and Single disc. Hydraulic. rear brakes. The Honda CBR 300R ABS was launched in 2015, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model id: CBR300R.
