2016 Harley-Davidson Dyna Low Rider Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Harley-Davidson Dyna Low Rider.

Basic Specs

Year2016
MakeHarley-Davidson
ModelHarley-Davidson Dyna Low Rider
CostUS$ 14339. Euro 16335. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1690.00 ccm (103.12 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.6:1
Bore/Stroke98.3 x 111.1 mm (3.9 x 4.4 inches)
Valves/Cylinder
FuelingInjection. ESPFI
Ignition
Exhaust2-into-1 exhaust with a deep rumble
LubricationDry sump
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
DrivelinePrimary chain, 57/38 ratio

Performance

Horespower76.10 HP (55.5 kW)
Torque125.00 Nm (12.7 kgf-m or 92.2 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.50 litres/100 km (18.2 km/l or 42.77 mpg)
Fuel Capacity17.79 litres (4.70 gallons)
Emissions127.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake30.5°
Trail128 mm (5.1 inches)
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height680 mm (26.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,345 mm (92.3 inches)
Total Width
Ground Clearance105 mm (4.1 inches)
Wheelbase1,630 mm (64.2 inches)
Dry Weight298.0 kg (657.0 pounds)
Wet Weight311.0 kg (685.6 pounds)

Wheels & Brakes

Front Tire/Tyre100/90-H19
Rear Tire/Tyre160/70-V17
Front BrakesSingle disc. 4-piston fixed.
Front Brake Diameter
Rear BrakesSingle disc. 2-piston torque-free floating
Rear Brake Diameter
WheelsBlack, Split 5-Spoke Cast Aluminium

Comments

It appears you're interested in specifications for the Harley-Davidson Dyna Low Rider. This Custom / cruiser model is powered by a V2, four-stroke engine with 1690.00 ccm (103.12 cubic inches) of actual displacement before 9.6:1 compression. Fueling is metered via Injection. ESPFI allowing this machine to produce its 76.10 HP (55.5 kW) horsepower and 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) torque. According to our records engine heat of the Harley-Davidson Dyna Low Rider is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 100/90-H19 and the rear is 160/70-V17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. 4-piston fixed. front brakes and Single disc. 2-piston torque-free floating rear brakes. The Harley-Davidson Dyna Low Rider was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
