2016 Honda CRF80F Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Honda CRF80F.

Basic Specs

Year2016
MakeHonda
ModelHonda CRF80F
CostUS$ 2470. Prices depend on country, taxes, accessories, etc.

Engine

Displacement80.00 ccm (4.88 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.7:1
Bore/Stroke47.5 x 45.0 mm (1.9 x 1.8 inches)
Valves/Cylinder2
FuelingCarburettor. 20mm piston-valve carburator
IgnitionCD
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline#420 chain; 14T/46T

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity4.92 litres (1.30 gallons)
Emissions

Chassis

Frame TypeSteel
Rake28.0°
Trail74 mm (2.9 inches)
Front Suspension27.0mm leading-axle Showa fork
Front Travel90 mm (3.5 inches)
Rear SuspensionPro-Link Showa single shock
Rear Travel70 mm (2.8 inches)
Seat
Seat Height734 mm (28.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance218 mm (8.6 inches)
Wheelbase914 mm (36.0 inches)
Dry Weight
Wet Weight73.9 kg (163.0 pounds)

Wheels & Brakes

Front Tire/Tyre2.50-16
Rear Tire/Tyre3.60-14
Front BrakesExpanding brake (drum brake)
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
WheelsWire spoked

Comments

It appears you're interested in specifications for the Honda CRF80F. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 80.00 ccm (4.88 cubic inches) of actual displacement before 9.7:1 compression. Fueling is metered via Carburettor. 20mm piston-valve carburator allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda CRF80F is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 2.50-16 and the rear is 3.60-14 . The entire package is supported by the frame, Steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Expanding brake (drum brake) front brakes and Expanding brake (drum brake) rear brakes. The Honda CRF80F was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: CRF80F
