2016 Honda Forza 300 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Honda Forza 300.

Basic Specs

Year2016
MakeHonda
ModelHonda Forza 300
Cost Euro 4599. Prices depend on country, taxes, accessories, etc.

Engine

Displacement279.00 ccm (17.02 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.2:1
Bore/Stroke68.0 x 68.5 mm (2.7 x 2.7 inches)
Valves/Cylinder4
FuelingInjection. PGM-Fi
Ignition
Exhaust
LubricationForce-feed and splash
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
ClutchDry-type, multi-plate shoe
DrivelineCVT

Performance

Horespower25.48 HP (18.6 kW)
Torque26.00 Nm (2.7 kgf-m or 19.2 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption2.70 litres/100 km (37.0 km/l or 87.12 mpg)
Fuel Capacity12.00 litres (3.17 gallons)
Emissions62.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeUnderbone type
Rake27.0°
Trail92 mm (3.6 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionUnit Swing
Rear Travel
SeatTwo-person seat
Seat Height755 mm (29.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,180 mm (46.5 inches)
Total Length2,185 mm (86.0 inches)
Total Width750 mm (29.5 inches)
Ground Clearance135 mm (5.3 inches)
Wheelbase1,540 mm (60.6 inches)
Dry Weight201.0 kg (443.1 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/90-13
Rear Tire/Tyre140/70-13
Front BrakesSingle disc. ABS
Front Brake Diameter256 mm (10.1 inches)
Rear BrakesSingle disc. ABS
Rear Brake Diameter249 mm (9.8 inches)
Wheels6-spoke cast aluminium

Comments

It appears you're interested in specifications for the Honda Forza 300. This Scooter model is powered by a Single cylinder, four-stroke engine with 279.00 ccm (17.02 cubic inches) of actual displacement before 10.2:1 compression. Fueling is metered via Injection. PGM-Fi allowing this machine to produce its 25.48 HP (18.6 kW) horsepower and 26.00 Nm (2.7 kgf-m or 19.2 ft.lbs) torque. According to our records engine heat of the Honda Forza 300 is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 110/90-13 and the rear is 140/70-13 . The entire package is supported by the frame, Underbone type. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS front brakes and Single disc. ABS rear brakes. The Honda Forza 300 was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
