These are the known mechanical and performance specifications for your 2016 Ice Bear Magnum 300 Trike.
Basic Specs
Engine
Displacement276.00 ccm (16.84 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke72.9 x 66.8 mm (2.9 x 2.6 inches)
Valves/Cylinder
FuelingCarburettor
IgnitionCDI
Exhaust
Lubrication
CoolingLiquid
Performance
Horespower17.70 HP (12.9 kW)
Torque22.00 Nm (2.2 kgf-m or 16.2 ft.lbs)
Top Speed90.0 km/h (55.9 mph)
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity12.11 litres (3.20 gallons)
Emissions
Chassis
Frame TypeSteel
Rake
Trail
Front SuspensionDual Telescopic Forks
Front Travel
Rear SuspensionDual Shock
Rear Travel
Seat
Seat Height919 mm (36.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,140 mm (44.9 inches)
Total Length2,350 mm (92.5 inches)
Total Width1,049 mm (41.3 inches)
Ground Clearance150 mm (5.9 inches)
Wheelbase1,900 mm (74.8 inches)
Dry Weight200.0 kg (441.0 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre130/60-13
Rear Tire/Tyre190/50-12
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
WheelsTwo rear wheels
Comments
Small windscreen. Sold in the US. Made in China. Trike also called IceBear PST300R Magnum.
