These are the known mechanical and performance specifications for your 2016 Suzuki Burgman 400Z.

Basic Specs

Year2016
MakeSuzuki
ModelSuzuki Burgman 400Z
Cost

Engine

Displacement398.00 ccm (24.29 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression12.5:1
Bore/Stroke81.0 x 77.6 mm (3.2 x 3.1 inches)
Valves/Cylinder4
FuelingInjection
IgnitionTransistorized
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
Clutch
DrivelineV-belt Drive

Performance

Horespower33.00 HP (24.1 kW)
Torque34.30 Nm (3.5 kgf-m or 25.3 ft.lbs)
Top Speed140.0 km/h (87.0 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity13.25 litres (3.50 gallons)
Emissions

Chassis

Frame TypeHigh-tensile steel-tube
Rake
Trail
Front SuspensionTelescopic, coil spring, oil damped
Front Travel109 mm (4.3 inches)
Rear SuspensionLink type, coil spring, oil damped
Rear Travel99 mm (3.9 inches)
Seat
Seat Height710 mm (28.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,270 mm (89.4 inches)
Total Width825 mm (32.5 inches)
Ground Clearance125 mm (4.9 inches)
Wheelbase1,585 mm (62.4 inches)
Dry Weight
Wet Weight222.0 kg (489.4 pounds)

Wheels & Brakes

Front Tire/Tyre120/80-14
Rear Tire/Tyre150/70-13
Front BrakesDouble disc. Digital ABS
Front Brake Diameter
Rear BrakesSingle disc. Digital ABS
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Suzuki Burgman 400Z. This Scooter model is powered by a Single cylinder, four-stroke engine with 398.00 ccm (24.29 cubic inches) of actual displacement before 12.5:1 compression. Fueling is metered via Injection allowing this machine to produce its 33.00 HP (24.1 kW) horsepower and 34.30 Nm (3.5 kgf-m or 25.3 ft.lbs) torque. According to our records engine heat of the Suzuki Burgman 400Z is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/80-14 and the rear is 150/70-13 . The entire package is supported by the frame, High-tensile steel-tube. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Digital ABS front brakes and Single disc. Digital ABS rear brakes. The Suzuki Burgman 400Z was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Windscreen. Heated Grips.
