2016 Triumph Thruxton 1200 R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Triumph Thruxton 1200 R.

Basic Specs

Year2016
MakeTriumph
ModelTriumph Thruxton 1200 R
Cost

Engine

Displacement1200.00 ccm (73.22 cubic inches)
Type270º firing interval
DetailsTwin, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke97.6 x 80.0 mm (3.8 x 3.1 inches)
Valves/Cylinder4
FuelingInjection. Multipoint sequential electronic fuel injection with SAI
IgnitionDigital-inductive type via engine management system
ExhaustChromed 2 into 2 exhaust system with twin chrome silencers
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet. multi-plate
DrivelineO ring chain

Performance

Horespower97.00 HP (70.8 kW)
Torque112.00 Nm (11.4 kgf-m or 82.6 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption4.60 litres/100 km (21.7 km/l or 51.13 mpg)
Fuel Capacity14.50 litres (3.83 gallons)
Emissions106.7 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeTubular steel cradle
Rake22.8°
Trail92 mm (3.6 inches)
Front SuspensionShowa 43mm USD big piston forks, fully adjustable
Front Travel120 mm (4.7 inches)
Rear SuspensionFully adjustable Ohlins twin shocks with piggy back reservoir
Rear Travel120 mm (4.7 inches)
SeatSingle bullet seat
Seat Height810 mm (31.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,030 mm (40.6 inches)
Total Length2,150 mm (84.6 inches)
Total Width745 mm (29.3 inches)
Ground Clearance
Wheelbase1,415 mm (55.7 inches)
Dry Weight203.0 kg (447.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre160/60-ZR17
Front BrakesSingle disc. ABS. Bremo floating discs Brembo 4-piston radial monobloc calipers.
Front Brake Diameter310 mm (12.2 inches)
Rear BrakesSingle disc. ABS. Nissin 2-piston floating caliper, ABS
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Triumph Thruxton 1200 R. This Classic model is powered by a 270º firing interval Twin, four-stroke engine with 1200.00 ccm (73.22 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. Multipoint sequential electronic fuel injection with SAI allowing this machine to produce its 97.00 HP (70.8 kW) horsepower and 112.00 Nm (11.4 kgf-m or 82.6 ft.lbs) torque. According to our records engine heat of the Triumph Thruxton 1200 R is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 160/60-ZR17 . The entire package is supported by the frame, Tubular steel cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. Bremo floating discs Brembo 4-piston radial monobloc calipers. front brakes and Single disc. ABS. Nissin 2-piston floating caliper, ABS rear brakes. The Triumph Thruxton 1200 R was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
