2016 Znen TBX 260 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2016 Znen TBX 260.

Basic Specs

Year2016
MakeZnen
ModelZnen TBX 260
CostUS$ 2599. Prices depend on country, taxes, accessories, etc.

Engine

Displacement257.00 ccm (15.68 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke70.0 x 66.0 mm (2.8 x 2.6 inches)
Valves/Cylinder
Fueling
IgnitionElectronic
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
Clutch
DrivelineCVT

Performance

Horespower14.75 HP (10.8 kW)
Torque13.00 Nm (1.3 kgf-m or 9.6 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity13.25 litres (3.50 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionTelescopic
Front Travel
Rear SuspensionCoil over Shock
Rear Travel
Seat
Seat Height737 mm (29.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,295 mm (51.0 inches)
Total Length2,235 mm (88.0 inches)
Total Width762 mm (30.0 inches)
Ground Clearance
Wheelbase
Dry Weight130.2 kg (287.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/90-13
Rear Tire/Tyre130/60-13
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Znen TBX 260. This Scooter model is powered by a Single cylinder, four-stroke engine with 257.00 ccm (15.68 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via allowing this machine to produce its 14.75 HP (10.8 kW) horsepower and 13.00 Nm (1.3 kgf-m or 9.6 ft.lbs) torque. According to our records engine heat of the Znen TBX 260 is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 110/90-13 and the rear is 130/60-13 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Znen TBX 260 was launched in 2016, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Chinese scooter
