These are the known mechanical and performance specifications for your 2017 Honda CRF250M.
Basic Specs
Engine
Displacement249.60 ccm (15.23 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke76.0 x 55.0 mm (3.0 x 2.2 inches)
Valves/Cylinder
FuelingInjection. PGM-FI, 36mm throttle body
IgnitionComputer-controlled digital transistorized with electronic advance
Exhaust
Lubrication
CoolingLiquid
Drivetrain
Gearbox6-speed
Final DriveChain
ClutchWet multiplate with coil springs
Driveline#520 chain; 14T/40T
Performance
Horespower22.80 HP (16.6 kW)
Torque22.00 Nm (2.2 kgf-m or 16.2 ft.lbs)
Top Speed
Fuel Economy & Polution
Fuel Consumption3.22 litres/100 km (31.1 km/l or 73.05 mpg)
Fuel Capacity7.57 litres (2.00 gallons)
Emissions74.7 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis
Frame TypeSemi double cradle
Rake27.4°
Trail113 mm (4.4 inches)
Front Suspension43mm inverted fork
Front Travel61 mm (2.4 inches)
Rear SuspensionPro-Link® single shock with spring; 9.4 inches travel
Rear Travel61 mm (2.4 inches)
Seat
Seat Height881 mm (34.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,150 mm (45.3 inches)
Total Length2,125 mm (83.7 inches)
Total Width815 mm (32.1 inches)
Ground Clearance225 mm (8.9 inches)
Wheelbase1,445 mm (56.9 inches)
Dry Weight
Wet Weight146.0 kg (321.9 pounds)
Wheels & Brakes
Front Tire/Tyre110/70-17
Rear Tire/Tyre130/70-17
Front BrakesSingle disc. Two-piston calipers.
Front Brake Diameter256 mm (10.1 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels
