2017 Motorino XMb Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2017 Motorino XMb.

Basic Specs

Year2017
MakeMotorino
ModelMotorino XMb
CostUS$ 2690. Prices depend on country, taxes, accessories, etc.

Engine

Displacement
Type72V high-torque three-phase AC permanent-magnet brushless
DetailsElectric
Max RPM
Compression
Bore/Stroke
Valves/Cylinder
Fueling
Ignition
Exhaust
Lubrication
CoolingAir

Drivetrain

GearboxAutomatic
Final Drive
Clutch
Driveline

Performance

Horespower0.67 HP (0.5 kW)
Torque125.00 Nm (12.7 kgf-m or 92.2 ft.lbs)
Top Speed32.0 km/h (19.9 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity
Emissions

Chassis

Frame TypeHigh-tensile steel frame.
Rake
Trail
Front SuspensionDirect-acting twin internal spring/hydraulic shock.
Front Travel
Rear SuspensionTrailing arm twin adjustable-preload coil-over spring/hydraulic shocks.
Rear Travel
SeatDual seat
Seat Height820 mm (32.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length1,800 mm (70.9 inches)
Total Width
Ground Clearance
Wheelbase1,200 mm (47.2 inches)
Dry Weight50.0 kg (110.2 pounds)
Wet Weight91.0 kg (200.6 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-12
Rear Tire/Tyre120/70-12
Front BrakesSingle disc. ABS
Front Brake Diameter
Rear BrakesSingle disc. ABS
Rear Brake Diameter
WheelsCast alloy.

Comments

It appears you're interested in specifications for the Motorino XMb. This Scooter model is powered by a 72V high-torque three-phase AC permanent-magnet brushless Electric engine with of actual displacement before compression. Fueling is metered via allowing this machine to produce its 0.67 HP (0.5 kW) horsepower and 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) torque. According to our records engine heat of the Motorino XMb is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-12 and the rear is 120/70-12 . The entire package is supported by the frame, High-tensile steel frame.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS front brakes and Single disc. ABS rear brakes. The Motorino XMb was launched in 2017, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Charging time 7.5hrs with various options. 72V 20A-h sealed lead-acid main battery. Optional 72V 26A-h Lithium Ion (LiFePO4) battery. Regenerative rear breaking. Sold in Canada and the US.
