2017 Pitster Pro LXR 250F MX - Enduro EFI Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2017 Pitster Pro LXR 250F MX - Enduro EFI.

Basic Specs

Year2017
MakePitster Pro
ModelPitster Pro LXR 250F MX - Enduro EFI
CostUS$ 4499. Prices depend on country, taxes, accessories, etc.

Engine

Displacement250.00 ccm (15.26 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression11.6:1
Bore/Stroke77.0 x 53.6 mm (3.0 x 2.1 inches)
Valves/Cylinder4
FuelingInjection. Delphi
IgnitionCDI
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower32.00 HP (23.4 kW)
Torque28.48 Nm (2.9 kgf-m or 21.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.71 litres (2.30 gallons)
Emissions

Chassis

Frame TypeLight weight central backbone chromo
Rake
Trail
Front SuspensionTelescopic, cartridge type, compression and rebound adjustable
Front Travel305 mm (12.0 inches)
Rear SuspensionLinkage, spring preload w/ fully adjustable compression and rebound
Rear Travel
Seat
Seat Height945 mm (37.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,270 mm (50.0 inches)
Total Length2,149 mm (84.6 inches)
Total Width833 mm (32.8 inches)
Ground Clearance335 mm (13.2 inches)
Wheelbase1,481 mm (58.3 inches)
Dry Weight112.0 kg (247.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre80/100-21
Rear Tire/Tyre100/90-18
Front BrakesSingle disc. Hydraulic.
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Hydraulic.
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Pitster Pro LXR 250F MX - Enduro EFI. This Cross / motocross model is powered by a Single cylinder, four-stroke engine with 250.00 ccm (15.26 cubic inches) of actual displacement before 11.6:1 compression. Fueling is metered via Injection. Delphi allowing this machine to produce its 32.00 HP (23.4 kW) horsepower and 28.48 Nm (2.9 kgf-m or 21.0 ft.lbs) torque. According to our records engine heat of the Pitster Pro LXR 250F MX - Enduro EFI is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 80/100-21 and the rear is 100/90-18 . The entire package is supported by the frame, Light weight central backbone chromo . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. front brakes and Single disc. Hydraulic. rear brakes. The Pitster Pro LXR 250F MX - Enduro EFI was launched in 2017, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Can be modified to an enduro bike with a kit.
