2017 Rieju CityLine 125 IE ABS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2017 Rieju CityLine 125 IE ABS.

Basic Specs

Year2017
MakeRieju
ModelRieju CityLine 125 IE ABS
Cost

Engine

Displacement125.00 ccm (7.63 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke57.0 x 48.6 mm (2.2 x 1.9 inches)
Valves/Cylinder4
FuelingInjection
Ignition
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
ClutchCVT
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.50 litres (2.25 gallons)
Emissions

Chassis

Frame TypeRigid tubular steel
Rake
Trail
Front SuspensionHydraulic Forks 36mm
Front Travel
Rear SuspensionTwin shocks with adjustable preload
Rear Travel
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,375 mm (54.1 inches)
Total Length1,980 mm (78.0 inches)
Total Width790 mm (31.1 inches)
Ground Clearance
Wheelbase1,410 mm (55.5 inches)
Dry Weight170.0 kg (374.8 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-14
Rear Tire/Tyre140/60-14
Front BrakesSingle disc. Wave disc. ABS.
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Wave disc.
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Rieju CityLine 125 IE ABS. This Scooter model is powered by a Single cylinder, four-stroke engine with 125.00 ccm (7.63 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its horsepower and torque. According to our records engine heat of the Rieju CityLine 125 IE ABS is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/70-14 and the rear is 140/60-14 . The entire package is supported by the frame, Rigid tubular steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Wave disc. ABS. front brakes and Single disc. Wave disc. rear brakes. The Rieju CityLine 125 IE ABS was launched in 2017, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Spanish made scooter.
