2018 Harley-Davidson Softail Breakout 114 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2018 Harley-Davidson Softail Breakout 114.

Basic Specs

Year2018
MakeHarley-Davidson
ModelHarley-Davidson Softail Breakout 114
CostUS$ 20299. Euro 22995. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1868.00 ccm (113.99 cubic inches)
TypeMilwaukee-Eight 114 Big Twin
DetailsV2, four-stroke
Max RPM
Compression15.0:1
Bore/Stroke102.0 x 114.3 mm (4.0 x 4.5 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection
Ignition
Exhaust2-into-2 staggered; catalyst in muffler
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
DrivelineChain, 34/46 ratio primary drive

Performance

Horespower94.00 HP (68.6 kW)
Torque155.00 Nm (15.8 kgf-m or 114.3 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.50 litres/100 km (18.2 km/l or 42.77 mpg)
Fuel Capacity13.20 litres (3.49 gallons)
Emissions127.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake34.0°
Trail145 mm (5.7 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionTwin shocks
Rear Travel
Seat
Seat Height665 mm (26.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,370 mm (93.3 inches)
Total Width
Ground Clearance115 mm (4.5 inches)
Wheelbase1,695 mm (66.7 inches)
Dry Weight294.0 kg (648.2 pounds)
Wet Weight305.0 kg (672.4 pounds)

Wheels & Brakes

Front Tire/Tyre130/60-B21
Rear Tire/Tyre240/40-R18
Front BrakesSingle disc. ABS. 4-piston
Front Brake Diameter
Rear BrakesSingle disc. ABS. 2-piston
Rear Brake Diameter
WheelsGloss black, Gasser II cast aluminum

Comments

It appears you're interested in specifications for the Harley-Davidson Softail Breakout 114. This Custom / cruiser model is powered by a Milwaukee-Eight 114 Big Twin V2, four-stroke engine with 1868.00 ccm (113.99 cubic inches) of actual displacement before 15.0:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection allowing this machine to produce its 94.00 HP (68.6 kW) horsepower and 155.00 Nm (15.8 kgf-m or 114.3 ft.lbs) torque. According to our records engine heat of the Harley-Davidson Softail Breakout 114 is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/60-B21 and the rear is 240/40-R18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. 4-piston front brakes and Single disc. ABS. 2-piston rear brakes. The Harley-Davidson Softail Breakout 114 was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
