2018 Harley-Davidson Sportster 1200 Custom Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2018 Harley-Davidson Sportster 1200 Custom.

Basic Specs

Year2018
MakeHarley-Davidson
ModelHarley-Davidson Sportster 1200 Custom
CostUS$ 10999. Euro 12275. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1201.25 ccm (73.30 cubic inches)
TypeAir-cooled, Evolution®
DetailsV2, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke88.9 x 96.8 mm (3.5 x 3.8 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Ignition
ExhaustChrome, staggered exhaust with slash-cut mufflers
LubricationDry sump
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
Driveline

Performance

Horespower67.00 HP (48.9 kW)
Torque96.00 Nm (9.8 kgf-m or 70.8 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.20 litres/100 km (19.2 km/l or 45.23 mpg)
Fuel Capacity17.00 litres (4.49 gallons)
Emissions120.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake30.0°
Trail107 mm (4.2 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionTwin shocks
Rear Travel
Seat
Seat Height725 mm (28.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,225 mm (87.6 inches)
Total Width
Ground Clearance105 mm (4.1 inches)
Wheelbase1,530 mm (60.2 inches)
Dry Weight255.0 kg (562.2 pounds)
Wet Weight268.0 kg (590.8 pounds)

Wheels & Brakes

Front Tire/Tyre130/90-B16
Rear Tire/Tyre150/80-B16
Front BrakesSingle disc. Dual piston, optional ABS.
Front Brake Diameter
Rear BrakesSingle disc. Dual piston, optional ABS.
Rear Brake Diameter
WheelsChrome, 5-Spoke Cast Aluminum

Comments

It appears you're interested in specifications for the Harley-Davidson Sportster 1200 Custom. This Custom / cruiser model is powered by a Air-cooled, Evolution® V2, four-stroke engine with 1201.25 ccm (73.30 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection (ESPFI) allowing this machine to produce its 67.00 HP (48.9 kW) horsepower and 96.00 Nm (9.8 kgf-m or 70.8 ft.lbs) torque. According to our records engine heat of the Harley-Davidson Sportster 1200 Custom is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/90-B16 and the rear is 150/80-B16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Dual piston, optional ABS. front brakes and Single disc. Dual piston, optional ABS. rear brakes. The Harley-Davidson Sportster 1200 Custom was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
