2018 Moto Guzzi Eldorado Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2018 Moto Guzzi Eldorado.

Basic Specs

Year2018
MakeMoto Guzzi
ModelMoto Guzzi Eldorado
CostUS$ 16490. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1380.00 ccm (84.21 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression10.5:1
Bore/Stroke104.0 x 81.2 mm (4.1 x 3.2 inches)
Valves/Cylinder4
FuelingInjection. Weber-Marelli electronic fuel injection.
Ignition
ExhaustStainless steel, 2-in-2 type, 3-way catalytic converter with double oxygen sensor
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveShaft drive (cardan)
ClutchDry single plate with flexible couplings
DrivelineCA.R.C. Compact Reactive Shaft Drive

Performance

Horespower96.00 HP (70.1 kW)
Torque121.00 Nm (12.3 kgf-m or 89.2 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.44 litres (5.40 gallons)
Emissions

Chassis

Frame TypeDouble cradle tubular frame in ALS steel with detachable rear subframe
Rake33.0°
Trail144 mm (5.7 inches)
Front SuspensionStandard swingarm 46 mm, with radical calliper mountain bracket and telescopes on the stanchions
Front Travel120 mm (4.7 inches)
Rear SuspensionSwingarm with double shock absorber adjustable spring preload
Rear Travel120 mm (4.7 inches)
Seat
Seat Height740 mm (29.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,113 mm (43.8 inches)
Total Length2,445 mm (96.3 inches)
Total Width940 mm (37.0 inches)
Ground Clearance165 mm (6.5 inches)
Wheelbase1,695 mm (66.7 inches)
Dry Weight
Wet Weight314.0 kg (692.3 pounds)

Wheels & Brakes

Front Tire/Tyre100/90-18
Rear Tire/Tyre130/80-17
Front BrakesDouble disc. ABS. Floating discs.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Floating disc.
Rear Brake Diameter282 mm (11.1 inches)
WheelsPolished aluminum, spoked. Metzeler Lasertec tyres.

Comments

It appears you're interested in specifications for the Moto Guzzi Eldorado. This Classic model is powered by a V2, four-stroke engine with 1380.00 ccm (84.21 cubic inches) of actual displacement before 10.5:1 compression. Fueling is metered via Injection. Weber-Marelli electronic fuel injection. allowing this machine to produce its 96.00 HP (70.1 kW) horsepower and 121.00 Nm (12.3 kgf-m or 89.2 ft.lbs) torque. According to our records engine heat of the Moto Guzzi Eldorado is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 100/90-18 and the rear is 130/80-17 . The entire package is supported by the frame, Double cradle tubular frame in ALS steel with detachable rear subframe. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. front brakes and Single disc. ABS. Floating disc. rear brakes. The Moto Guzzi Eldorado was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Ride by Wire with 3 engine maps
