2018 Triumph Tiger 1200 XCX Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2018 Triumph Tiger 1200 XCX.

Basic Specs

Year2018
MakeTriumph
ModelTriumph Tiger 1200 XCX
CostUS$ 16500. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1215.00 ccm (74.14 cubic inches)
Type
DetailsIn-line three, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke85.0 x 71.4 mm (3.3 x 2.8 inches)
Valves/Cylinder4
FuelingInjection
Ignition
ExhaustStainless steel 3 into 1 side mounted stainless steel silencer
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveShaft drive (cardan)
ClutchWet, multi-plate hydraulically operated, torque assist
Driveline

Performance

Horespower139.00 HP (101.5 kW)
Torque122.00 Nm (12.4 kgf-m or 90.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption4.90 litres/100 km (20.4 km/l or 48.00 mpg)
Fuel Capacity20.00 litres (5.28 gallons)
Emissions113.7 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeTubular steel trellis frame. Single-­sided, cast aluminium alloy swing arm with shaft drive.
Rake23.2°
Trail100 mm (3.9 inches)
Front SuspensionWP 48 mm upside down forks, electronically adjustable damping,
Front Travel190 mm (7.5 inches)
Rear SuspensionWP monoshock, electronically adjustable semi active damping,
Rear Travel193 mm (7.6 inches)
Seat
Seat Height835 mm (32.9 inches) If adjustable, lowest setting.
Alt. Seat Height855 mm (33.7 inches) If adjustable, highest setting.
Total Height1,470 mm (57.9 inches)
Total Length2,248 mm (88.5 inches)
Total Width885 mm (34.8 inches)
Ground Clearance
Wheelbase1,520 mm (59.8 inches)
Dry Weight242.0 kg (533.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-R19
Rear Tire/Tyre170/60-R17
Front BrakesDouble disc. Floating discs, radially mounted monobloc Brembo calipers, 4-piston, switchable ABS.
Front Brake Diameter305 mm (12.0 inches)
Rear BrakesSingle disc. Nissin 2-piston sliding caliper, switchable ABS
Rear Brake Diameter282 mm (11.1 inches)
WheelsCast aluminum alloy 10-spoke

Comments

It appears you're interested in specifications for the Triumph Tiger 1200 XCX. This Allround model is powered by a In-line three, four-stroke engine with 1215.00 ccm (74.14 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection allowing this machine to produce its 139.00 HP (101.5 kW) horsepower and 122.00 Nm (12.4 kgf-m or 90.0 ft.lbs) torque. According to our records engine heat of the Triumph Tiger 1200 XCX is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 120/70-R19 and the rear is 170/60-R17 . The entire package is supported by the frame, Tubular steel trellis frame. Single-­sided, cast aluminium alloy swing arm with shaft drive.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Floating discs, radially mounted monobloc Brembo calipers, 4-piston, switchable ABS. front brakes and Single disc. Nissin 2-piston sliding caliper, switchable ABS rear brakes. The Triumph Tiger 1200 XCX was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Windscreen. Auxiliary lights. Engine protection bars. Hand guards. Sump guard. Advanced On Board computer. Cruise Control. Semi Active Suspension.
