These are the known mechanical and performance specifications for your 2018 UM Renegade Sport S.

Basic Specs

Year2018
MakeUM
ModelUM Renegade Sport S
TypeSport
Cost Euro 3399. Prices depend on country, taxes, accessories, etc.

Engine

Displacement124.60 ccm (7.60 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke52.4 x 57.8 mm (2.1 x 2.3 inches)
Valves/Cylinder
FuelingInjection. Mikuni
IgnitionCDI
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower12.07 HP (8.8 kW)
Torque10.00 Nm (1.0 kgf-m or 7.4 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity18.00 litres (4.76 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionHydraulic Telescopic fork
Front Travel110 mm (4.3 inches)
Rear SuspensionHydraulic Telescopic. /Gas - Spring Shockabsorber.
Rear Travel65 mm (2.6 inches)
Seat
Seat Height770 mm (30.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,140 mm (44.9 inches)
Total Length2,280 mm (89.8 inches)
Total Width800 mm (31.5 inches)
Ground Clearance140 mm (5.5 inches)
Wheelbase1,550 mm (61.0 inches)
Dry Weight153.0 kg (337.3 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/80-17
Rear Tire/Tyre140/80-15
Front BrakesSingle disc. Hydraulic.
Front Brake Diameter280 mm (11.0 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the UM Renegade Sport S. This Sport model is powered by a Single cylinder, four-stroke engine with 124.60 ccm (7.60 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. Mikuni allowing this machine to produce its 12.07 HP (8.8 kW) horsepower and 10.00 Nm (1.0 kgf-m or 7.4 ft.lbs) torque. According to our records engine heat of the UM Renegade Sport S is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 110/80-17 and the rear is 140/80-15 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. front brakes and Expanding brake (drum brake) rear brakes. The UM Renegade Sport S was launched in 2018, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
