2019 Harley-Davidson Softail Breakout Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2019 Harley-Davidson Softail Breakout.

Basic Specs

Year2019
MakeHarley-Davidson
ModelHarley-Davidson Softail Breakout
CostUS$ 19049. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1746.00 ccm (106.54 cubic inches)
TypeMilwaukee-Eight® 107, optional 114 Big Twin.
DetailsV2, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke100.0 x 111.0 mm (3.9 x 4.4 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection
Ignition
Exhaust2-into-2 staggered; catalyst in muffler
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
DrivelineChain, 34/46 ratio primary drive

Performance

Horespower86.00 HP (62.8 kW)
Torque147.80 Nm (15.1 kgf-m or 109.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Fuel Capacity13.20 litres (3.49 gallons)
Emissions116.0 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake34.0°
Trail145 mm (5.7 inches)
Front SuspensionTelescopic fork
Front Travel
Rear SuspensionTwin shocks
Rear Travel
Seat
Seat Height665 mm (26.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,370 mm (93.3 inches)
Total Width
Ground Clearance115 mm (4.5 inches)
Wheelbase1,695 mm (66.7 inches)
Dry Weight294.0 kg (648.2 pounds)
Wet Weight305.0 kg (672.4 pounds)

Wheels & Brakes

Front Tire/Tyre130/60-B21
Rear Tire/Tyre240/40-R18
Front BrakesSingle disc. ABS. 4-piston
Front Brake Diameter
Rear BrakesSingle disc. ABS. 2-piston
Rear Brake Diameter
WheelsGloss black, Gasser II cast aluminum

Comments

It appears you're interested in specifications for the Harley-Davidson Softail Breakout. This Custom / cruiser model is powered by a Milwaukee-Eight® 107, optional 114 Big Twin. V2, four-stroke engine with 1746.00 ccm (106.54 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection allowing this machine to produce its 86.00 HP (62.8 kW) horsepower and 147.80 Nm (15.1 kgf-m or 109.0 ft.lbs) torque. According to our records engine heat of the Harley-Davidson Softail Breakout is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/60-B21 and the rear is 240/40-R18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. 4-piston front brakes and Single disc. ABS. 2-piston rear brakes. The Harley-Davidson Softail Breakout was launched in 2019, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
