2019 Honda CRF250L Rally Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2019 Honda CRF250L Rally.

Basic Specs

Year2019
MakeHonda
ModelHonda CRF250L Rally
Cost

Engine

Displacement249.60 ccm (15.23 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke76.0 x 55.0 mm (3.0 x 2.2 inches)
Valves/Cylinder
FuelingInjection. PGM-FI, 38mm throttle body
IgnitionComputer-controlled digital transistorized with electronic advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet multiplate with coil springs
Driveline#520 chain; 14T/40T

Performance

Horespower22.80 HP (16.6 kW)
Torque22.00 Nm (2.2 kgf-m or 16.2 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.95 litres (2.10 gallons)
Emissions

Chassis

Frame Type
Rake27.6°
Trail113 mm (4.4 inches)
Front Suspension43mm inverted fork
Front Travel249 mm (9.8 inches)
Rear SuspensionPro-Link® single shock with spring; 9.4 inches travel
Rear Travel239 mm (9.4 inches)
Seat
Seat Height874 mm (34.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance269 mm (10.6 inches)
Wheelbase1,445 mm (56.9 inches)
Dry Weight
Wet Weight144.0 kg (317.5 pounds)

Wheels & Brakes

Front Tire/Tyre3.00-21
Rear Tire/Tyre120/80-18
Front BrakesDouble disc. Two-piston calipers.
Front Brake Diameter256 mm (10.1 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda CRF250L Rally. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 249.60 ccm (15.23 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-FI, 38mm throttle body allowing this machine to produce its 22.80 HP (16.6 kW) horsepower and 22.00 Nm (2.2 kgf-m or 16.2 ft.lbs) torque. According to our records engine heat of the Honda CRF250L Rally is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 3.00-21 and the rear is 120/80-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Two-piston calipers. front brakes and Single disc rear brakes. The Honda CRF250L Rally was launched in 2019, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Rally-style bodywork and windscreen. Model ID: CRF250LH
