2019 Suzuki Katana Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2019 Suzuki Katana.

Basic Specs

Year2019
MakeSuzuki
ModelSuzuki Katana
TypeSport
Cost

Engine

Displacement999.00 ccm (60.96 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression12.2:1
Bore/Stroke73.0 x 59.0 mm (2.9 x 2.3 inches)
Valves/Cylinder4
FuelingInjection
Ignition
Exhaust4-2-1 exhaust system
LubricationWet sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower147.51 HP (107.7 kW)
Torque108.00 Nm (11.0 kgf-m or 79.7 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity12.00 litres (3.17 gallons)
Emissions

Chassis

Frame Type
Rake25.0°
Trail100 mm (3.9 inches)
Front SuspensionInverted telescopic, coil spring, oil damped
Front Travel120 mm (4.7 inches)
Rear SuspensionLink type, single shock, coil spring, oil damped
Rear Travel
Seat
Seat Height825 mm (32.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,110 mm (43.7 inches)
Total Length2,125 mm (83.7 inches)
Total Width830 mm (32.7 inches)
Ground Clearance140 mm (5.5 inches)
Wheelbase1,460 mm (57.5 inches)
Dry Weight
Wet Weight215.0 kg (474.0 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/50-ZR17
Front BrakesDouble disc
Front Brake Diameter310 mm (12.2 inches)
Rear BrakesSingle disc. ABS, Nissin 1-piston
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Suzuki Katana. This Sport model is powered by a In-line four, four-stroke engine with 999.00 ccm (60.96 cubic inches) of actual displacement before 12.2:1 compression. Fueling is metered via Injection allowing this machine to produce its 147.51 HP (107.7 kW) horsepower and 108.00 Nm (11.0 kgf-m or 79.7 ft.lbs) torque. According to our records engine heat of the Suzuki Katana is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/50-ZR17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc. ABS, Nissin 1-piston rear brakes. The Suzuki Katana was launched in 2019, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
