2020 Honda CRF250L Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Honda CRF250L.

Basic Specs

Honda CRF250L
Year2020
MakeHonda
ModelHonda CRF250L
CostUS$ 5199. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement249.6 ccm (15.23 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke76.0 x 55.0 mm (3.0 x 2.2 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI, 38mm throttle body
IgnitionComputer-controlled digital transistorized with electronic advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet multiplate with coil springs
Driveline#520 chain; 14T/40T

Performance

Horespower22.8 HP (16.6 kW) @ 8500 RPM
Torque22.0 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption3.22 litres/100 km (31.1 km/l or 73.05 mpg)
Fuel Capacity7.95 litres (2.10 US gallons)
Emissions74.7 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake27.6 deg
Trail113 mm (4.4 inches)
Front Suspension43mm inverted fork
Front Travel249 mm (9.8 inches)
Rear SuspensionPro-Link® single shock with spring;
Rear Travel239 mm (9.4 inches)
Seat
Seat Height874 mm (34.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1195 mm (47.0 inches)
Total Length2195 mm (86.4 inches)
Total Width815 mm (32.1 inches)
Ground Clearance254 mm (10.0 inches)
Wheelbase1445 mm (56.9 inches)
Dry Weight
Wet Weight146.0 kg (321.9 pounds)

Wheels & Brakes

Front Tire/Tyre3.00-21
Rear Tire/Tyre120/80-18
Front BrakesSingle disc. Two-piston calipers.
Front Brake Diameter256 mm (10.1 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda CRF250L. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 249.6 ccm (15.23 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-FI, 38mm throttle body allowing this machine to produce its 22.8 HP (16.6 kW) @ 8500 RPM horsepower and 22.0 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 RPM torque. According to our records engine heat of the Honda CRF250L is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 3.00-21 and the rear is 120/80-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Two-piston calipers. front brakes and Single disc rear brakes. The Honda CRF250L was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: CRF250L.
