2020 Honda Monkey Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Honda Monkey.

Basic Specs

Honda Monkey
Year2020
MakeHonda
ModelHonda Monkey
CostUS$ 3999. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement124.9 ccm (7.62 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.3:1
Bore/Stroke52.4 x 57.9 mm (2.1 x 2.3 inches)
Valves/Cylinder2
FuelingInjection. PGM-FI with automatic enrichment
IgnitionFully transistorized
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox4-speed
Final Drive
ClutchWet, multiplate
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity5.68 litres (1.50 US gallons)
Emissions

Chassis

Frame Type
Rake25.0 deg
Trail81 mm (3.2 inches)
Front SuspensionTelescopic fork
Front Travel99 mm (3.9 inches)
Rear SuspensionTwin shocks
Rear Travel104 mm (4.1 inches)
Seat
Seat Height777 mm (30.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1156 mm (45.5 inches)
Dry Weight
Wet Weight105.0 kg (231.5 pounds)

Wheels & Brakes

Front Tire/Tyre120/80-12
Rear Tire/Tyre130/80-12
Front BrakesSingle disc. Hydraulic. Optional ABS.
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc. Hydraulic. Optional ABS.
Rear Brake Diameter190 mm (7.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda Monkey. This Allround model is powered by a Single cylinder, four-stroke engine with 124.9 ccm (7.62 cubic inches) of actual displacement before 9.3:1 compression. Fueling is metered via Injection. PGM-FI with automatic enrichment allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda Monkey is moderated by Air. You'll need to get familiar with the 4-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/80-12 and the rear is 130/80-12 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. Optional ABS. front brakes and Single disc. Hydraulic. Optional ABS. rear brakes. The Honda Monkey was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model id: MONKEY125.
