2020 Honda Rebel 500 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Honda Rebel 500.

Basic Specs

Honda Rebel 500
Year2020
MakeHonda
ModelHonda Rebel 500
TypeSport
Cost

Engine

Displacement471.0 ccm (28.74 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke67.0 x 66.8 mm (2.6 x 2.6 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI with 34mm throttle bodies
IgnitionFull transistorized ignition
Exhaust2-1 exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchSlipper clutch
DrivelineO-ring-sealed chain

Performance

Horespower46.9 HP (34.3 kW) @ 8500 RPM
Torque43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 7000 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption3.51 litres/100 km (28.5 km/l or 67.01 mpg)
Fuel Capacity11.20 litres (2.96 US gallons)
Emissions81.4 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake28.0 deg
Trail110 mm (4.3 inches)
Front Suspension41mm telescopic fork
Front Travel122 mm (4.8 inches)
Rear SuspensionDual shocks
Rear Travel97 mm (3.8 inches)
Seat
Seat Height690 mm (27.2 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1094 mm (43.1 inches)
Total Length2188 mm (86.1 inches)
Total Width820 mm (32.3 inches)
Ground Clearance136 mm (5.4 inches)
Wheelbase1488 mm (58.6 inches)
Dry Weight
Wet Weight185.1 kg (408.0 pounds)

Wheels & Brakes

Front Tire/Tyre130/90-16
Rear Tire/Tyre150/80-16
Front BrakesSingle disc. Hydraulic
Front Brake Diameter
Rear BrakesSingle disc. Hydraulic
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Honda Rebel 500. This Sport model is powered by a Twin, four-stroke engine with 471.0 ccm (28.74 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-FI with 34mm throttle bodies allowing this machine to produce its 46.9 HP (34.3 kW) @ 8500 RPM horsepower and 43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 7000 RPM torque. According to our records engine heat of the Honda Rebel 500 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 130/90-16 and the rear is 150/80-16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic front brakes and Single disc. Hydraulic rear brakes. The Honda Rebel 500 was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model id: CMX500.
