2020 Honda Shadow Aero Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Honda Shadow Aero.

Basic Specs

Honda Shadow Aero
Year2020
MakeHonda
ModelHonda Shadow Aero
CostUS$ 7699. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement745.0 ccm (45.46 cubic inches)
Type52 degrees V-twin
DetailsV2, four-stroke
Max RPM
Compression9.6:1
Bore/Stroke79.0 x 76.0 mm (3.1 x 3.0 inches)
Valves/Cylinder3
FuelingInjection. PGM-FI with automatic enrichment circuit, 34mm throttle body
IgnitionDigital transistorized with electronic advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final Drive
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption4.20 litres/100 km (23.8 km/l or 56.00 mpg)
Fuel Capacity14.00 litres (3.70 US gallons)
Emissions97.4 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake34.0 deg
Trail161 mm (6.3 inches)
Front Suspension41mm fork
Front Travel117 mm (4.6 inches)
Rear SuspensionDual shocks with five-position spring-preload adjustability
Rear Travel89 mm (3.5 inches)
Seat
Seat Height658 mm (25.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1638 mm (64.5 inches)
Dry Weight
Wet Weight254.0 kg (560.0 pounds)

Wheels & Brakes

Front Tire/Tyre120/90-17
Rear Tire/Tyre160/80-15
Front BrakesSingle disc. Two-piston calipers.
Front Brake Diameter296 mm (11.7 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter180 mm (7.1 inches)
WheelsWire spoked

Comments

It appears you're interested in specifications for the Honda Shadow Aero. This Custom / cruiser model is powered by a 52 degrees V-twin V2, four-stroke engine with 745.0 ccm (45.46 cubic inches) of actual displacement before 9.6:1 compression. Fueling is metered via Injection. PGM-FI with automatic enrichment circuit, 34mm throttle body allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda Shadow Aero is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/90-17 and the rear is 160/80-15 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Two-piston calipers. front brakes and Expanding brake (drum brake) rear brakes. The Honda Shadow Aero was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model id: VT750C.
