2020 Husqvarna FX 350 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Husqvarna FX 350.

Basic Specs

Husqvarna FX 350
Year2020
MakeHusqvarna
ModelHusqvarna FX 350
CostUS$ 10499. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement349.7 ccm (21.34 cubic inches)
TypePolished camshafts and DLC coated finger followers
DetailsSingle cylinder, four-stroke
Max RPM
Compression11.1:1
Bore/Stroke88.0 x 57.5 mm (3.5 x 2.3 inches)
Valves/Cylinder4
FuelingCarburettor
IgnitionKeihin EMS
Exhaust
LubricationForced oil lubrication with 2 Eaton pumps
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet, DDS multi-disc clutch, Magura hydraulics
Driveline5/8 x 1/4

Performance

Horespower58.0 HP (42.3 kW)
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.50 litres (2.25 US gallons)
Emissions

Chassis

Frame Type25CrMo4 steel central-tube
Rake26.5 deg
Trail
Front SuspensionWP-USD, AER 48, Ø 48 mm
Front Travel310 mm (12.2 inches)
Rear SuspensionWP shock absorber with linkage
Rear Travel300 mm (11.8 inches)
Seat
Seat Height950 mm (37.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance370 mm (14.6 inches)
Wheelbase1482 mm (58.3 inches)
Dry Weight100.6 kg (221.8 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre140/80-18
Front BrakesSingle disc. Brembo twin-piston floating calliper
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Brembo single-piston floating calliper
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Husqvarna FX 350. This Enduro / offroad model is powered by a Polished camshafts and DLC coated finger followers Single cylinder, four-stroke engine with 349.7 ccm (21.34 cubic inches) of actual displacement before 11.1:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 58.0 HP (42.3 kW) horsepower and torque. According to our records engine heat of the Husqvarna FX 350 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 140/80-18 . The entire package is supported by the frame, 25CrMo4 steel central-tube. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Brembo twin-piston floating calliper front brakes and Single disc. Brembo single-piston floating calliper rear brakes. The Husqvarna FX 350 was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
