2020 Husqvarna TX 300i Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Husqvarna TX 300i.

Basic Specs

Husqvarna TX 300i
Year2020
MakeHusqvarna
ModelHusqvarna TX 300i
CostUS$ 10099. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement293.2 ccm (17.89 cubic inches)
TypeReed valves, counter balancer shaft
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke72.0 x 72.0 mm (2.8 x 2.8 inches)
Valves/Cylinder
FuelingCarburettor. 38mm flat slide Mikuni TMX
IgnitionKokusan EMS
Exhaust
LubricationMixture oil lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet, multi-disc clutch, Magura hydraulics
DrivelineConstant mesh

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.50 litres (2.25 US gallons)
Emissions

Chassis

Frame Type25CrMo4 steel central-tube
Rake26.5 deg
Trail106 mm (4.2 inches)
Front SuspensionWP-USD Xplor 48 with preload adjuster
Front Travel310 mm (12.2 inches)
Rear SuspensionWP shock absorber with linkage
Rear Travel300 mm (11.8 inches)
Seat
Seat Height950 mm (37.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance370 mm (14.6 inches)
Wheelbase1485 mm (58.5 inches)
Dry Weight
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre140/90-18
Front BrakesSingle disc. Magura twin-piston floating calliper
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Magura single-piston floating calliper
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Husqvarna TX 300i. This Enduro / offroad model is powered by a Reed valves, counter balancer shaft Single cylinder, two-stroke engine with 293.2 ccm (17.89 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor. 38mm flat slide Mikuni TMX allowing this machine to produce its horsepower and torque. According to our records engine heat of the Husqvarna TX 300i is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 140/90-18 . The entire package is supported by the frame, 25CrMo4 steel central-tube. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Magura twin-piston floating calliper front brakes and Single disc. Magura single-piston floating calliper rear brakes. The Husqvarna TX 300i was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
