2020 Indian Roadmaster Dark Horse Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Indian Roadmaster Dark Horse.

Basic Specs

Indian Roadmaster Dark Horse
Year2020
MakeIndian
ModelIndian Roadmaster Dark Horse
Cost

Engine

Displacement1901.0 ccm (116.00 cubic inches)
TypeThunder Stroke® 116
DetailsV2, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke103.2 x 113.0 mm (4.1 x 4.4 inches)
Valves/Cylinder
FuelingInjection. Closed loop fuel injection / 54 mm bore
Ignition
ExhaustSplit dual exhaust with cross-over
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final Drive
ClutchGear Drive Wet Clutch
Driveline

Performance

Horespower
Torque170.9 Nm (17.4 kgf-m or 126.0 ft.lbs) @ 2900 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.80 litres (5.50 US gallons)
Emissions

Chassis

Frame TypeCast Aluminum Frame with Integrated Air-Box
Rake25.0 deg
Trail150 mm (5.9 inches)
Front SuspensionTelescopic fork
Front Travel119 mm (4.7 inches)
Rear SuspensionSingle shock with air adjust
Rear Travel114 mm (4.5 inches)
Seat
Seat Height673 mm (26.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1491 mm (58.7 inches)
Total Length2693 mm (106.0 inches)
Total Width1000 mm (39.4 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1668 mm (65.7 inches)
Dry Weight398.0 kg (877.4 pounds)
Wet Weight408.0 kg (899.5 pounds)

Wheels & Brakes

Front Tire/Tyre130/60-B16
Rear Tire/Tyre180/60-R16
Front BrakesDouble disc. ABS. Floating discs. 4 piston caliper.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. Floating disc. 2-piston caliper.
Rear Brake Diameter300 mm (11.8 inches)
WheelsCast wheels. Dunlop® Elite 3 tires.

Comments

It appears you're interested in specifications for the Indian Roadmaster Dark Horse. This Touring model is powered by a Thunder Stroke® 116 V2, four-stroke engine with 1901.0 ccm (116.00 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. Closed loop fuel injection / 54 mm bore allowing this machine to produce its horsepower and 170.9 Nm (17.4 kgf-m or 126.0 ft.lbs) @ 2900 RPM torque. According to our records engine heat of the Indian Roadmaster Dark Horse is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 130/60-B16 and the rear is 180/60-R16 . The entire package is supported by the frame, Cast Aluminum Frame with Integrated Air-Box. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. 4 piston caliper. front brakes and Single disc. ABS. Floating disc. 2-piston caliper. rear brakes. The Indian Roadmaster Dark Horse was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
