2020 Jawa-CZ 660 Sportard Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Jawa-CZ 660 Sportard.

Basic Specs

Jawa-CZ 660 Sportard
Year2020
MakeJawa-CZ
ModelJawa-CZ 660 Sportard
Cost

Engine

Displacement660.0 ccm (40.27 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke100.0 x 84.0 mm (3.9 x 3.3 inches)
Valves/Cylinder4
FuelingCarburettor. Bing
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final Drive
Clutch
Driveline

Performance

Horespower48.3 HP (35.2 kW) @ 6000 RPM
Torque57.5 Nm (5.9 kgf-m or 42.4 ft.lbs) @ 5000 RPM
Top Speed160.0 km/h (99.4 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 US gallons)
Emissions

Chassis

Frame TypeTubular
Rake
Trail
Front SuspensionTelescopic forks
Front Travel150 mm (5.9 inches)
Rear SuspensionBitubo shocks
Rear Travel170 mm (6.7 inches)
Seat
Seat Height825 mm (32.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1500 mm (59.1 inches)
Dry Weight198.0 kg (436.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre150/70-17
Front BrakesDouble disc
Front Brake Diameter305 mm (12.0 inches)
Rear BrakesSingle disc
Rear Brake Diameter280 mm (11.0 inches)
Wheels

Comments

It appears you're interested in specifications for the Jawa-CZ 660 Sportard. This Super motard model is powered by a Single cylinder, four-stroke engine with 660.0 ccm (40.27 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Carburettor. Bing allowing this machine to produce its 48.3 HP (35.2 kW) @ 6000 RPM horsepower and 57.5 Nm (5.9 kgf-m or 42.4 ft.lbs) @ 5000 RPM torque. According to our records engine heat of the Jawa-CZ 660 Sportard is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 150/70-17 . The entire package is supported by the frame, Tubular. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Jawa-CZ 660 Sportard was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
