2020 Kawasaki Ninja 650L Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Kawasaki Ninja 650L.

Basic Specs

Kawasaki Ninja 650L
Year2020
MakeKawasaki
ModelKawasaki Ninja 650L
TypeSport
Cost

Engine

Displacement649.0 ccm (39.60 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.8:1
Bore/Stroke83.0 x 60.0 mm (3.3 x 2.4 inches)
Valves/Cylinder2
FuelingInjection. DFI® with dual 38mm Keihin throttle bodies
IgnitionTCBI with digital advance
Exhaust
LubricationForced lubrication, semi-dry sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
Clutch
DrivelineO-Ring Chain

Performance

Horespower67.3 HP (49.1 kW) @ 8000 RPM
Torque66.0 Nm (6.7 kgf-m or 48.7 ft.lbs) @ 6500 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 US gallons)
Emissions

Chassis

Frame TypeTrellis, high-tensile steel
Rake24.0 deg
Trail99 mm (3.9 inches)
Front Suspension41mm hydraulic telescopic fork
Front Travel124 mm (4.9 inches)
Rear SuspensionHorizontal back-link with adjustable spring preload
Rear Travel130 mm (5.1 inches)
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1135 mm (44.7 inches)
Total Length2055 mm (80.9 inches)
Total Width740 mm (29.1 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1410 mm (55.5 inches)
Dry Weight
Wet Weight192.0 kg (423.3 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre160/60-17
Front BrakesDouble disc. Petal discs and two-piston calipers. ABS.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. Petal disc and single piston caliper. ABS.
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Ninja 650L. This Sport model is powered by a Twin, four-stroke engine with 649.0 ccm (39.60 cubic inches) of actual displacement before 10.8:1 compression. Fueling is metered via Injection. DFI® with dual 38mm Keihin throttle bodies allowing this machine to produce its 67.3 HP (49.1 kW) @ 8000 RPM horsepower and 66.0 Nm (6.7 kgf-m or 48.7 ft.lbs) @ 6500 RPM torque. According to our records engine heat of the Kawasaki Ninja 650L is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 160/60-17 . The entire package is supported by the frame, Trellis, high-tensile steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Petal discs and two-piston calipers. ABS. front brakes and Single disc. Petal disc and single piston caliper. ABS. rear brakes. The Kawasaki Ninja 650L was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
