2020 Paton S1-R 60 Anniversario Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2020 Paton S1-R 60 Anniversario.

Basic Specs

Paton S1-R 60 Anniversario
Year2020
MakePaton
ModelPaton S1-R 60 Anniversario
TypeSport
Cost

Engine

Displacement649.0 ccm (39.60 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.8:1
Bore/Stroke83.0 x 60.0 mm (3.3 x 2.4 inches)
Valves/Cylinder
FuelingInjection. Keihin, 38mmx2
Ignition
ExhaustDouble stainless steel pipes
LubricationDry sump
CoolingLiquid

Drivetrain

Gearbox
Final Drive
ClutchWet multi-disc clutch
Driveline

Performance

Horespower71.1 HP (51.9 kW) @ 8500 RPM
Torque64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7000 RPM
Top Speed250.0 km/h (155.3 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity16.00 litres (4.23 US gallons)
Emissions

Chassis

Frame Type
Rake
Trail105 mm (4.1 inches)
Front SuspensionOhlins 43mm upside down forks.
Front Travel120 mm (4.7 inches)
Rear SuspensionOhlins Double shock absorbers
Rear Travel130 mm (5.1 inches)
Seat
Seat Height810 mm (31.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1100 mm (43.3 inches)
Total Length1980 mm (78.0 inches)
Total Width680 mm (26.8 inches)
Ground Clearance
Wheelbase1390 mm (54.7 inches)
Dry Weight
Wet Weight158.0 kg (348.3 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre180/55-17
Front BrakesDouble disc
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Paton S1-R 60 Anniversario. This Sport model is powered by a Twin, four-stroke engine with 649.0 ccm (39.60 cubic inches) of actual displacement before 10.8:1 compression. Fueling is metered via Injection. Keihin, 38mmx2 allowing this machine to produce its 71.1 HP (51.9 kW) @ 8500 RPM horsepower and 64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7000 RPM torque. According to our records engine heat of the Paton S1-R 60 Anniversario is moderated by Liquid. You'll need to get familiar with the transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 180/55-17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Paton S1-R 60 Anniversario was launched in 2020, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
