2021 BMW S 1000 XR Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 BMW S 1000 XR.

Basic Specs

BMW S 1000 XR
Year2021
MakeBMW
ModelBMW S 1000 XR
TypeSport
CostUS$ 17945. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement999.0 ccm (60.96 cubic inches)
TypeTitanium valves
DetailsIn-line four, four-stroke
Max RPM
Compression12.5:1
Bore/Stroke80.0 x 49.7 mm (3.1 x 2.0 inches)
Valves/Cylinder4
FuelingInjection. Electronic Injection
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchMultiplate clutch in oil bath, slipper clutch, self-reinforcing
DrivelineChain 17/45

Performance

Horespower165.0 HP (120.4 kW) @ 11000 RPM
Torque114.0 Nm (11.6 kgf-m or 84.1 ft.lbs) @ 9250 RPM
Top Speed200.0 km/h (124.3 mph)

Fuel Economy & Polution

Fuel Consumption6.36 litres/100 km (15.7 km/l or 36.98 mpg)
Fuel Capacity20.00 litres (5.28 US gallons)
Emissions147.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeAluminium composite bridge frame, partially self-supporting engine
Rake24.9 deg
Trail116 mm (4.6 inches)
Front SuspensionUpside-down telescopic fork 46 mm, compression and rebound stage adjustable
Front Travel150 mm (5.9 inches)
Rear SuspensionAluminium double-sided swing-arm, central spring strut, electronic preload adjuster, electronic self-adjusting rebound/compression damping
Rear Travel150 mm (5.9 inches)
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height838 mm (33.0 inches) If adjustable, highest setting.
Total Height1411 mm (55.6 inches)
Total Length2333 mm (91.9 inches)
Total Width917 mm (36.1 inches)
Ground Clearance
Wheelbase1548 mm (60.9 inches)
Dry Weight
Wet Weight226.0 kg (498.2 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/55-ZR17
Front BrakesDouble disc. ABS. Floating discs. Four-piston fixed calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Twin piston floating disc.
Rear Brake Diameter265 mm (10.4 inches)
WheelsCast Aluminium

Comments

It appears you're interested in specifications for the BMW S 1000 XR. This Sport model is powered by a Titanium valves In-line four, four-stroke engine with 999.0 ccm (60.96 cubic inches) of actual displacement before 12.5:1 compression. Fueling is metered via Injection. Electronic Injection allowing this machine to produce its 165.0 HP (120.4 kW) @ 11000 RPM horsepower and 114.0 Nm (11.6 kgf-m or 84.1 ft.lbs) @ 9250 RPM torque. According to our records engine heat of the BMW S 1000 XR is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/55-ZR17 . The entire package is supported by the frame, Aluminium composite bridge frame, partially self-supporting engine. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Floating discs. Four-piston fixed calipers. front brakes and Single disc. ABS. Twin piston floating disc. rear brakes. The BMW S 1000 XR was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Riding Modes Pro (incl. HSC Pro, MSR, ABS Pro and DTC). Integrated Pannier Holders.
