2021 Cleveland Ace 400 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Cleveland Ace 400.

Basic Specs

Cleveland Ace 400
Year2021
MakeCleveland
ModelCleveland Ace 400
CostUS$ 3995. MSRP depends on country, taxes, accessories, etc.

Engine

Displacement397.0 ccm (24.22 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression8.8:1
Bore/Stroke85.0 x 70.0 mm (3.3 x 2.8 inches)
Valves/Cylinder
FuelingInjection. Delphi
IgnitionCDI
Exhaust
Lubrication
CoolingOil & air

Drivetrain

Gearbox5-speed
Final Drive
ClutchWet, multi-disc
Driveline

Performance

Horespower42.0 HP (30.7 kW) @ 9200 RPM
Torque34.0 Nm (3.5 kgf-m or 25.1 ft.lbs) @ 7650 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 US gallons)
Emissions

Chassis

Frame TypeTubular backbone, double cradle
Rake
Trail
Front SuspensionInverted forks
Front Travel
Rear SuspensionTwin coil over oil damped shocks
Rear Travel
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2050 mm (80.7 inches)
Total Width795 mm (31.3 inches)
Ground Clearance
Wheelbase1410 mm (55.5 inches)
Dry Weight150.0 kg (330.7 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-18
Rear Tire/Tyre120/80-16
Front BrakesDouble disc. ABS, 4 piston radial mount caliper
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS
Rear Brake Diameter220 mm (8.7 inches)
WheelsWire spoked

Comments

It appears you're interested in specifications for the Cleveland Ace 400. This Classic model is powered by a Single cylinder, four-stroke engine with 397.0 ccm (24.22 cubic inches) of actual displacement before 8.8:1 compression. Fueling is metered via Injection. Delphi allowing this machine to produce its 42.0 HP (30.7 kW) @ 9200 RPM horsepower and 34.0 Nm (3.5 kgf-m or 25.1 ft.lbs) @ 7650 RPM torque. According to our records engine heat of the Cleveland Ace 400 is moderated by Oil & air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-18 and the rear is 120/80-16 . The entire package is supported by the frame, Tubular backbone, double cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS, 4 piston radial mount caliper front brakes and Single disc. ABS rear brakes. The Cleveland Ace 400 was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

US brand also called Cleveland Cycle Werks (CCW). Bike made in China.
