2021 Fantic XE 125 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Fantic XE 125.

Basic Specs

Fantic XE 125
Year2021
MakeFantic
ModelFantic XE 125
Cost

Engine

Displacement125.0 ccm (7.63 cubic inches)
Type
DetailsSingle cylinder, two-stroke
Max RPM
Compression8.8:1
Bore/Stroke54.5 x 54.0 mm (2.1 x 2.1 inches)
Valves/Cylinder4
FuelingCarburettor. Mikuni 38
IgnitionCDI
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet-  multi-disc
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity9.00 litres (2.38 US gallons)
Emissions

Chassis

Frame TypeAluminum semi double cradle
Rake26.8 deg
Trail116 mm (4.6 inches)
Front SuspensionKYB ø48 mm, fully adjustable
Front Travel300 mm (11.8 inches)
Rear SuspensionKYB, fully adjustable
Rear Travel315 mm (12.4 inches)
Seat
Seat Height955 mm (37.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1285 mm (50.6 inches)
Total Length2140 mm (84.3 inches)
Total Width825 mm (32.5 inches)
Ground Clearance
Wheelbase1455 mm (57.3 inches)
Dry Weight
Wet Weight96.0 kg (211.6 pounds)

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre120/90-18
Front BrakesSingle disc. Wave disc
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Wave disc
Rear Brake Diameter220 mm (8.7 inches)
WheelsAluminium, anodized black, wire spoked

Comments

It appears you're interested in specifications for the Fantic XE 125. This Enduro / offroad model is powered by a Single cylinder, two-stroke engine with 125.0 ccm (7.63 cubic inches) of actual displacement before 8.8:1 compression. Fueling is metered via Carburettor. Mikuni 38 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Fantic XE 125 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 120/90-18 . The entire package is supported by the frame, Aluminum semi double cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Wave disc front brakes and Single disc. Wave disc rear brakes. The Fantic XE 125 was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
