These are the known mechanical and performance specifications for your 2021 Harley-Davidson Pan America 1250.
Basic Specs
Year2021
MakeHarley-Davidson
ModelHarley-Davidson Pan America 1250
TypeEnduro / offroad
CostUS$ 19999. MSRP depends on country, taxes, accessories, etc.
Engine
Displacement1250.4 ccm (76.30 cubic inches)
TypeRevolution® Max 1250 engine
DetailsV2, four-stroke
Max RPM
Compression13.0:1
Bore/Stroke104.9 x 72.4 mm (4.1 x 2.9 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection
Ignition
Exhaust2-into-1-into-1; catalyst in header
LubricationDry sump
CoolingLiquid
Performance
Horespower150.0 HP (109.5 kW) @ 9000 RPM
Torque127.5 Nm (13.0 kgf-m or 94.0 ft.lbs) @ 6750 RPM
Top Speed
Fuel Economy & Polution
Fuel Consumption5.11 litres/100 km (19.6 km/l or 46.03 mpg)
Fuel Capacity21.20 litres (5.60 US gallons)
Emissions118.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis
Frame Type
Rake25.0 deg
Trail157 mm (6.2 inches)
Front Suspension47mm inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps.
Front Travel190 mm (7.5 inches)
Rear SuspensionLinkage-mounted monoshock with automatic electronic preload control and semi-active compression and rebound damping
Rear Travel
SeatTwo-up seat.
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2266 mm (89.2 inches)
Total Width
Ground Clearance211 mm (8.3 inches)
Wheelbase1580 mm (62.2 inches)
Dry Weight239.0 kg (527.0 pounds)
Wet Weight253.6 kg (559.0 pounds)
Wheels & Brakes
Front Tire/Tyre120/70-R19
Rear Tire/Tyre170/60-R17
Front BrakesDouble disc. Radially mounted, monoblock, 4-piston caliper. Optional ABS.
Front Brake Diameter
Rear BrakesSingle disc. Floating, single piston caliper. Optional ABS.
Rear Brake Diameter
WheelsAluminum cast, black
Comments
Available from May 2021. Windscreen, cruise control, six-axis IMU, customizable ride modes, Bluetooth connectivity and moving map navigation.
