These are the known mechanical and performance specifications for your 2021 Hero Maestro Edge 125 BS6.
Basic Specs
Engine
Displacement124.6 ccm (7.60 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke53.0 x 49.5 mm (2.1 x 1.9 inches)
Valves/Cylinder
FuelingInjection
Ignition
Exhaust
Lubrication
CoolingAir
Performance
Horespower9.0 HP (6.6 kW) @ 7000 RPM
Torque10.4 Nm (1.1 kgf-m or 7.7 ft.lbs) @ 5500 RPM
Top Speed
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity5.00 litres (1.32 US gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front SuspensionTelescopic, Hydraulic Shock Absorbers
Front Travel
Rear SuspensionUnit Swing with Spring Loaded Hydraulic Damper
Rear Travel
Seat
Seat Height775 mm (30.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1188 mm (46.8 inches)
Total Length1843 mm (72.6 inches)
Total Width718 mm (28.3 inches)
Ground Clearance155 mm (6.1 inches)
Wheelbase1261 mm (49.6 inches)
Dry Weight
Wet Weight112.0 kg (246.9 pounds)
Wheels & Brakes
Front Tire/Tyre90/90-12
Rear Tire/Tyre90/100-10
Front BrakesExpanding brake (drum brake)
Front Brake Diameter190 mm (7.5 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter130 mm (5.1 inches)
Wheels
