2021 Honda NC750X Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Honda NC750X.

Basic Specs

Honda NC750X
Year2021
MakeHonda
ModelHonda NC750X
Cost

Engine

Displacement745.0 ccm (45.46 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.7:1
Bore/Stroke77.0 x 80.0 mm (3.0 x 3.1 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI electronic fuel injection
IgnitionComputer controlled digital transistorised with electronic advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
Clutch2 multiplate wet
Driveline16T/43T; chain

Performance

Horespower57.8 HP (42.2 kW) @ 6000 RPM
Torque69.0 Nm (7.0 kgf-m or 50.9 ft.lbs) @ 4750 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption3.50 litres/100 km (28.6 km/l or 67.21 mpg)
Fuel Capacity14.10 litres (3.73 US gallons)
Emissions81.2 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeDiamond; steel pipe
Rake27.0 deg
Trail110 mm (4.3 inches)
Front Suspension41mm telescopic fork
Front Travel120 mm (4.7 inches)
Rear SuspensionMonoshock damper, Pro-Link swingarm
Rear Travel120 mm (4.7 inches)
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1330 mm (52.4 inches)
Total Length2210 mm (87.0 inches)
Total Width846 mm (33.3 inches)
Ground Clearance145 mm (5.7 inches)
Wheelbase1534 mm (60.4 inches)
Dry Weight
Wet Weight214.0 kg (471.8 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre160/60-ZR17
Front BrakesSingle disc. ABS. Hydraulic. Two-piston calipers.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. ABS. Hydraulic. Single-piston caliper.
Rear Brake Diameter240 mm (9.4 inches)
WheelsMulti-Spoke Aluminium Cast

Comments

It appears you're interested in specifications for the Honda NC750X. This Super motard model is powered by a Twin, four-stroke engine with 745.0 ccm (45.46 cubic inches) of actual displacement before 10.7:1 compression. Fueling is metered via Injection. PGM-FI electronic fuel injection allowing this machine to produce its 57.8 HP (42.2 kW) @ 6000 RPM horsepower and 69.0 Nm (7.0 kgf-m or 50.9 ft.lbs) @ 4750 RPM torque. According to our records engine heat of the Honda NC750X is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 160/60-ZR17 . The entire package is supported by the frame, Diamond; steel pipe. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS. Hydraulic. Two-piston calipers. front brakes and Single disc. ABS. Hydraulic. Single-piston caliper. rear brakes. The Honda NC750X was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
