These are the known mechanical and performance specifications for your 2021 KTM 350 EXC TPI Erzberg Rodeo.
Basic Specs

Engine
Displacement349.7 ccm (21.34 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke88.0 x 57.5 mm (3.5 x 2.3 inches)
Valves/Cylinder
FuelingInjection
IgnitionKeihin EMS
Exhaust
Lubrication
CoolingLiquid
Drivetrain
Gearbox6-speed
Final Drive
ClutchWet, DDS multi-disc clutch, Brembo hydraulics
Driveline5/8 x 1/4´ chain
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity8.50 litres (2.25 US gallons)
Emissions
Chassis
Frame TypeCentral double-cradle-type 25CrMo4 steel
Rake26.5 deg
Trail
Front SuspensionWP XACT-USD, Ø 48 mm
Front Travel300 mm (11.8 inches)
Rear SuspensionWP XACT Monoshock with linkage
Rear Travel310 mm (12.2 inches)
Seat
Seat Height960 mm (37.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance355 mm (14.0 inches)
Wheelbase1482 mm (58.3 inches)
Dry Weight107.8 kg (237.7 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre1.60-21
Rear Tire/Tyre2.15-19
Front BrakesSingle disc
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels
