2021 Paton S1-R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2021 Paton S1-R .

Basic Specs

Paton S1-R
Year2021
MakePaton
ModelPaton S1-R
TypeSport
Cost

Engine

Displacement649.0 ccm (39.60 cubic inches)
Type
DetailsTwo cylinder boxer, four-stroke
Max RPM
Compression10.8:1
Bore/Stroke83.0 x 60.0 mm (3.3 x 2.4 inches)
Valves/Cylinder4
FuelingCarburettor. Keihin, 38mm
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final Drive
ClutchWet multi-disc
Driveline

Performance

Horespower71.1 HP (51.9 kW) @ 8500 RPM
Torque64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7000 RPM
Top Speed220.0 km/h (136.7 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity16.00 litres (4.23 US gallons)
Emissions

Chassis

Frame Type
Rake24.5 deg
Trail105 mm (4.1 inches)
Front SuspensionOhlins FGRT204 upside down forks.
Front Travel130 mm (5.1 inches)
Rear SuspensionDual shocks, Ohlins
Rear Travel130 mm (5.1 inches)
Seat
Seat Height810 mm (31.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1100 mm (43.3 inches)
Total Length1980 mm (78.0 inches)
Total Width680 mm (26.8 inches)
Ground Clearance
Wheelbase1390 mm (54.7 inches)
Dry Weight
Wet Weight165.0 kg (363.8 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
WheelsMetzeler Racetec RR tires.

Comments

It appears you're interested in specifications for the Paton S1-R . This Sport model is powered by a Two cylinder boxer, four-stroke engine with 649.0 ccm (39.60 cubic inches) of actual displacement before 10.8:1 compression. Fueling is metered via Carburettor. Keihin, 38mm allowing this machine to produce its 71.1 HP (51.9 kW) @ 8500 RPM horsepower and 64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7000 RPM torque. According to our records engine heat of the Paton S1-R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Paton S1-R was launched in 2021, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Italian brand.
