2022 Honda Monkey 125 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2022 Honda Monkey 125.

Basic Specs

Honda Monkey 125
Year2022
MakeHonda
ModelHonda Monkey 125
Cost

Engine

Displacement124.9 ccm (7.62 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke50.0 x 63.1 mm (2.0 x 2.5 inches)
Valves/Cylinder2
FuelingInjection. PGM-FI with automatic enrichment
IgnitionFully transistorized
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final Drive
ClutchWet, multiplate
Driveline

Performance

Horespower9.3 HP (6.8 kW) @ 6750 RPM
Torque11.0 Nm (1.1 kgf-m or 8.1 ft.lbs) @ 5500 RPM
Top Speed

Fuel Economy & Polution

Fuel Consumption1.50 litres/100 km (66.7 km/l or 156.81 mpg)
Fuel Capacity5.68 litres (1.50 US gallons)
Emissions34.8 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeSteel backbone
Rake25.0 deg
Trail81 mm (3.2 inches)
Front Suspension31mm inverted fork
Front Travel100 mm (3.9 inches)
Rear SuspensionTwin shocks
Rear Travel102 mm (4.0 inches)
Seat
Seat Height775 mm (30.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1030 mm (40.6 inches)
Total Length1710 mm (67.3 inches)
Total Width755 mm (29.7 inches)
Ground Clearance175 mm (6.9 inches)
Wheelbase1156 mm (45.5 inches)
Dry Weight
Wet Weight104.0 kg (229.3 pounds)

Wheels & Brakes

Front Tire/Tyre120/80-12
Rear Tire/Tyre130/80-12
Front BrakesSingle disc. Hydraulic. Optional ABS.
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc. Hydraulic. Optional ABS.
Rear Brake Diameter190 mm (7.5 inches)
Wheels10-spoke cast aluminium

Comments

It appears you're interested in specifications for the Honda Monkey 125. This Allround model is powered by a Single cylinder, four-stroke engine with 124.9 ccm (7.62 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Injection. PGM-FI with automatic enrichment allowing this machine to produce its 9.3 HP (6.8 kW) @ 6750 RPM horsepower and 11.0 Nm (1.1 kgf-m or 8.1 ft.lbs) @ 5500 RPM torque. According to our records engine heat of the Honda Monkey 125 is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/80-12 and the rear is 130/80-12 . The entire package is supported by the frame, Steel backbone. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. Optional ABS. front brakes and Single disc. Hydraulic. Optional ABS. rear brakes. The Honda Monkey 125 was launched in 2022, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model id: MONKEY125. IMU control reduces rear lift under braking.
