1933 BMW R16 series 4 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 1933 BMW R16 series 4.

Basic Specs

Year1933
MakeBMW
ModelBMW R16 series 4
Cost

Engine

Displacement736.00 ccm (44.91 cubic inches)
Type
DetailsTwo cylinder boxer, four-stroke
Max RPM
Compression7.0:1
Bore/Stroke83.0 x 68.0 mm (3.3 x 2.7 inches)
Valves/Cylinder
FuelingCarburettor. Amal 26mm
IgnitionMagneto
Exhaust
LubricationWet sump
CoolingAir

Drivetrain

Gearbox3-speed
Final DriveShaft drive (cardan)
ClutchDry-single plate-cable operated
Driveline

Performance

Horespower33.00 HP (24.1 kW)
Torque
Top Speed126.0 km/h (78.3 mph)

Fuel Economy & Polution

Fuel Consumption2.75 litres/100 km (36.4 km/l or 85.53 mpg)
Fuel Capacity14.00 litres (3.70 gallons)
Emissions63.8 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypePressed steel duplex
Rake
Trail
Front SuspensionLeading link
Front Travel
Rear SuspensionRigid
Rear Travel
SeatSolo seat with springs
Seat Height
Alt. Seat Height
Total Height950 mm (37.4 inches)
Total Length2,100 mm (82.7 inches)
Total Width890 mm (35.0 inches)
Ground Clearance
Wheelbase1,380 mm (54.3 inches)
Dry Weight
Wet Weight165.0 kg (363.8 pounds)

Wheels & Brakes

Front Tire/Tyre3.5-26
Rear Tire/Tyre3.5-26
Front BrakesExpanding brake (drum brake)
Front Brake Diameter200 mm (7.9 inches)
Rear Brakes
Rear Brake Diameter55 mm (2.2 inches)
Wheels

Comments

It appears you're interested in specifications for the BMW R16 series 4. This Allround model is powered by a Two cylinder boxer, four-stroke engine with 736.00 ccm (44.91 cubic inches) of actual displacement before 7.0:1 compression. Fueling is metered via Carburettor. Amal 26mm allowing this machine to produce its 33.00 HP (24.1 kW) horsepower and torque. According to our records engine heat of the BMW R16 series 4 is moderated by Air. You'll need to get familiar with the 3-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 3.5-26 and the rear is 3.5-26 . The entire package is supported by the frame, Pressed steel duplex. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Expanding brake (drum brake) front brakes and rear brakes. The BMW R16 series 4 was launched in 1933, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
