1999 Kawasaki Vulcan 1500 Nomad Specs

motorcycle specs

These are the known mechanical and performance specifications for your 1999 Kawasaki Vulcan 1500 Nomad.

Basic Specs

Year1999
MakeKawasaki
ModelKawasaki Vulcan 1500 Nomad
Cost

Engine

Displacement1470.00 ccm (89.70 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression8.6:1
Bore/Stroke102.0 x 90.0 mm (4.0 x 3.5 inches)
Valves/Cylinder2
FuelingCarburettor
IgnitionElectric
ExhaustDouble chrome pipes
LubricationWet Sump
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
ClutchWet plate, multiple
Driveline

Performance

Horespower51.00 HP (37.2 kW)
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption6.75 litres/100 km (14.8 km/l or 34.85 mpg)
Fuel Capacity15.89 litres (4.20 gallons)
Emissions156.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeSteel
Rake32.0°
Trail188 mm (7.4 inches)
Front Suspension41mm stanchions
Front Travel150 mm (5.9 inches)
Rear Suspensiondual dampers, adjustable for air-pressure, rebound damping
Rear Travel99 mm (3.9 inches)
Seat
Seat Height719 mm (28.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,510 mm (98.8 inches)
Total Width826 mm (32.5 inches)
Ground Clearance
Wheelbase1,666 mm (65.6 inches)
Dry Weight
Wet Weight351.5 kg (775.0 pounds)

Wheels & Brakes

Front Tire/Tyre150/80-19 71H
Rear Tire/Tyre150/80-19 71H
Front BrakesDouble disc. Single-action, twin-piston calipers
Front Brake Diameter279 mm (11.0 inches)
Rear BrakesSingle disc. Single-action
Rear Brake Diameter318 mm (12.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Vulcan 1500 Nomad. This Touring model is powered by a Twin, four-stroke engine with 1470.00 ccm (89.70 cubic inches) of actual displacement before 8.6:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 51.00 HP (37.2 kW) horsepower and torque. According to our records engine heat of the Kawasaki Vulcan 1500 Nomad is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 150/80-19 71H and the rear is 150/80-19 71H . The entire package is supported by the frame, Steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Single-action, twin-piston calipers front brakes and Single disc. Single-action rear brakes. The Kawasaki Vulcan 1500 Nomad was launched in 1999, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
