2003 Suzuki GSF 1200 S Bandit Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2003 Suzuki GSF 1200 S Bandit.

Basic Specs

Year2003
MakeSuzuki
ModelSuzuki GSF 1200 S Bandit
Cost

Engine

Displacement1157.00 ccm (70.60 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke79.0 x 59.0 mm (3.1 x 2.3 inches)
Valves/Cylinder4
FuelingCarburettor
Ignition
Exhaust
Lubrication
Cooling

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower98.00 HP (71.5 kW)
Torque91.70 Nm (9.4 kgf-m or 67.6 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.00 litres (5.28 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,070 mm (81.5 inches)
Total Width765 mm (30.1 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,430 mm (56.3 inches)
Dry Weight220.0 kg (485.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre180/55-17
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Suzuki GSF 1200 S Bandit. This Sport touring model is powered by a In-line four, four-stroke engine with 1157.00 ccm (70.60 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 98.00 HP (71.5 kW) horsepower and 91.70 Nm (9.4 kgf-m or 67.6 ft.lbs) torque. According to our records engine heat of the Suzuki GSF 1200 S Bandit is moderated by . You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 180/55-17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Suzuki GSF 1200 S Bandit was launched in 2003, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
