2004 Ducati Monster S4 R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2004 Ducati Monster S4 R.

Basic Specs

Year2004
MakeDucati
ModelDucati Monster S4 R
Cost

Engine

Displacement996.00 ccm (60.78 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression11.6:1
Bore/Stroke98.0 x 66.0 mm (3.9 x 2.6 inches)
Valves/Cylinder4
FuelingInjection
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower113.00 HP (82.5 kW)
Torque95.50 Nm (9.7 kgf-m or 70.4 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 gallons)
Emissions

Chassis

Frame TypeTubular steel trellis
Rake24.0°
Trail
Front SuspensionShowa 43 mm fully adjustable upside-down fork with TiN surface treatment
Front Travel130 mm (5.1 inches)
Rear SuspensionProgressive linkage with Showa fully adjustable monoshock. Aluminium single-sided swingarm
Rear Travel148 mm (5.8 inches)
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,222 mm (48.1 inches)
Total Length2,121 mm (83.5 inches)
Total Width
Ground Clearance
Wheelbase1,440 mm (56.7 inches)
Dry Weight
Wet Weight193.0 kg (425.5 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc
Front Brake Diameter230 mm (9.1 inches)
Rear BrakesSingle disc
Rear Brake Diameter245 mm (9.6 inches)
Wheels

Comments

It appears you're interested in specifications for the Ducati Monster S4 R. This Naked bike model is powered by a V2, four-stroke engine with 996.00 ccm (60.78 cubic inches) of actual displacement before 11.6:1 compression. Fueling is metered via Injection allowing this machine to produce its 113.00 HP (82.5 kW) horsepower and 95.50 Nm (9.7 kgf-m or 70.4 ft.lbs) torque. According to our records engine heat of the Ducati Monster S4 R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, Tubular steel trellis. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Ducati Monster S4 R was launched in 2004, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

The S4R is the top of the range Monster - the most powerful, highest-performance Monster ever. It all starts with the 996 cc Superbike engine and lightweight Superbike-derived trellis frame to ensure the perfect combination of power and handling. A Showa fully-adjustable front fork with low friction TiN treatment and a fully-adjustable Showa rear shock handle suspension duties.
