These are the known mechanical and performance specifications for your 2005 Borile B651 Scrambler.
Basic Specs
Engine
Displacement652.34 ccm (39.81 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression8.5:1
Bore/Stroke94.0 x 94.0 mm (3.7 x 3.7 inches)
Valves/Cylinder4
FuelingCarburettor. Mikuni BS 40 SS
IgnitionElectronic
Exhaust
Lubrication
CoolingAir
Drivetrain
Gearbox5-speed
Final DriveChain
ClutchMultidisc in oil bath
Driveline
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity8.50 litres (2.25 gallons)
Emissions
Chassis
Frame TypeSplitted cradle in CR MO under the engine
Rake
Trail
Front SuspensionCeriani traditional fork Ø41, range 160
Front Travel
Rear Suspension2 shock absorbers Paioli, range 180
Rear Travel
Seat
Seat Height870 mm (34.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,120 mm (44.1 inches)
Total Length2,400 mm (94.5 inches)
Total Width820 mm (32.3 inches)
Ground Clearance250 mm (9.8 inches)
Wheelbase1,400 mm (55.1 inches)
Dry Weight142.0 kg (313.1 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre
Rear Tire/Tyre
Front BrakesSingle disc
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels
