2006 Yamaha TT-R125 - LW Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2006 Yamaha TT-R125 - LW.

Basic Specs

Year2006
MakeYamaha
ModelYamaha TT-R125 - LW
Cost

Engine

Displacement123.70 ccm (7.55 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke54.0 x 54.0 mm (2.1 x 2.1 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni TMX38
IgnitionCDI
Exhaust
LubricationPremix
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchWet, multiple-disc
Driveline

Performance

Horespower9.65 HP (7.0 kW)
Torque9.85 Nm (1.0 kgf-m or 7.3 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.00 litres (2.11 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionTelescopic fork
Front Travel180 mm (7.1 inches)
Rear SuspensionSwinging arm (monocross)
Rear Travel125 mm (4.9 inches)
Seat
Seat Height775 mm (30.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,055 mm (41.5 inches)
Total Length1,830 mm (72.0 inches)
Total Width785 mm (30.9 inches)
Ground Clearance265 mm (10.4 inches)
Wheelbase1,250 mm (49.2 inches)
Dry Weight84.0 kg (185.2 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre70/90-M17
Rear Tire/Tyre90/90-M14
Front BrakesSingle disc
Front Brake Diameter110 mm (4.3 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter110 mm (4.3 inches)
Wheels

Comments

It appears you're interested in specifications for the Yamaha TT-R125 - LW. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 123.70 ccm (7.55 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Carburettor. Mikuni TMX38 allowing this machine to produce its 9.65 HP (7.0 kW) horsepower and 9.85 Nm (1.0 kgf-m or 7.3 ft.lbs) torque. According to our records engine heat of the Yamaha TT-R125 - LW is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 70/90-M17 and the rear is 90/90-M14 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Expanding brake (drum brake) rear brakes. The Yamaha TT-R125 - LW was launched in 2006, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
