2007 Honda VT125C Shadow Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2007 Honda VT125C Shadow.

Basic Specs

Year2007
MakeHonda
ModelHonda VT125C Shadow
Cost

Engine

Displacement125.00 ccm (7.63 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression11.8:1
Bore/Stroke42.0 x 45.0 mm (1.7 x 1.8 inches)
Valves/Cylinder
FuelingCarburettor. 22mm VP-type x 2
IgnitionDigital transistorised with electronic advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower15.00 HP (10.9 kW)
Torque10.50 Nm (1.1 kgf-m or 7.7 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity14.00 litres (3.70 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front Suspension35mm telescopic fork, 110mm axle travel
Front Travel
Rear SuspensionDual dampers with adjustable preload, 80mm axle travel
Rear Travel
Seat
Seat Height680 mm (26.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,300 mm (90.6 inches)
Total Width
Ground Clearance145 mm (5.7 inches)
Wheelbase1,530 mm (60.2 inches)
Dry Weight145.0 kg (319.7 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre
Rear Tire/Tyre
Front BrakesDouble disc
Front Brake Diameter240 mm (9.4 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter130 mm (5.1 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda VT125C Shadow. This Custom / cruiser model is powered by a V2, four-stroke engine with 125.00 ccm (7.63 cubic inches) of actual displacement before 11.8:1 compression. Fueling is metered via Carburettor. 22mm VP-type x 2 allowing this machine to produce its 15.00 HP (10.9 kW) horsepower and 10.50 Nm (1.1 kgf-m or 7.7 ft.lbs) torque. According to our records engine heat of the Honda VT125C Shadow is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is and the rear is . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Expanding brake (drum brake) rear brakes. The Honda VT125C Shadow was launched in 2007, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
