2007 PGO Charge 125 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2007 PGO Charge 125.

Basic Specs

Year2007
MakePGO
ModelPGO Charge 125
Cost

Engine

Displacement124.90 ccm (7.62 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.4:1
Bore/Stroke51.5 x 60.0 mm (2.0 x 2.4 inches)
Valves/Cylinder
Fueling
IgnitionCDI
Exhaust
Lubrication
CoolingAir

Drivetrain

GearboxAutomatic
Final Drive
ClutchDry style, centrifugal type
Driveline

Performance

Horespower9.11 HP (6.6 kW)
Torque9.10 Nm (0.9 kgf-m or 6.7 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.50 litres (1.98 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionTelescopic (90mm extention)
Front Travel90 mm (3.5 inches)
Rear SuspensionUni-Absorber
Rear Travel
Seat
Seat Height
Alt. Seat Height
Total Height1,137 mm (44.8 inches)
Total Length1,815 mm (71.5 inches)
Total Width696 mm (27.4 inches)
Ground Clearance
Wheelbase1,129 mm (44.4 inches)
Dry Weight109.0 kg (240.3 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre100/90-10
Rear Tire/Tyre100/90-10
Front BrakesSingle disc. 190 mm Hydraulic Disk with Twin Piston Caliper
Front Brake Diameter190 mm (7.5 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter130 mm (5.1 inches)
Wheels

Comments

It appears you're interested in specifications for the PGO Charge 125. This Scooter model is powered by a Single cylinder, four-stroke engine with 124.90 ccm (7.62 cubic inches) of actual displacement before 9.4:1 compression. Fueling is metered via allowing this machine to produce its 9.11 HP (6.6 kW) horsepower and 9.10 Nm (0.9 kgf-m or 6.7 ft.lbs) torque. According to our records engine heat of the PGO Charge 125 is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 100/90-10 and the rear is 100/90-10 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. 190 mm Hydraulic Disk with Twin Piston Caliper front brakes and Expanding brake (drum brake) rear brakes. The PGO Charge 125 was launched in 2007, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
