2008 Diamo LS200 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Diamo LS200.

Basic Specs

Year2008
MakeDiamo
ModelDiamo LS200
CostUS$ 2495. Prices depend on country, taxes, accessories, etc.

Engine

Displacement199.00 ccm (12.14 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke
Valves/Cylinder
FuelingCarburettor
IgnitionC.D.I.
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower17.40 HP (12.7 kW)
Torque
Top Speed112.7 km/h (70.0 mph)

Fuel Economy & Polution

Fuel Consumption3.22 litres/100 km (31.1 km/l or 73.05 mpg)
Fuel Capacity7.57 litres (2.00 gallons)
Emissions74.7 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake
Trail
Front SuspensionTelescopic
Front Travel
Rear SuspensionMoncross
Rear Travel
Seat
Seat Height838 mm (33.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance254 mm (10.0 inches)
Wheelbase1,359 mm (53.5 inches)
Dry Weight118.8 kg (262.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre2.75-21
Rear Tire/Tyre4.10-18
Front BrakesSingle disc. ABS
Front Brake Diameter
Rear BrakesSingle disc. ABS
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Diamo LS200. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 199.00 ccm (12.14 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor allowing this machine to produce its 17.40 HP (12.7 kW) horsepower and torque. According to our records engine heat of the Diamo LS200 is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 2.75-21 and the rear is 4.10-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. ABS front brakes and Single disc. ABS rear brakes. The Diamo LS200 was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
